MiScope® Megapixel 2 Extended Field of View
The 2 megapixel extended field of view MiScope digital microscope offers a wider field of view with high resolution optical zoom and 2 micron resolution at maximum magnification.
The MiScope Megapixel 2EF takes the compact design of the MiScope and doubles the zoom ratio. An extended field of view (over 3 inches) provides 5 - 124x magnification, allowing you to see an entire signature and still zoom in for up to 120x magnification.
The higher resolution optics and 2 megapixel camera produce improved image quality, with resolution down to 2 microns. The MiScope Megapixel 2EF includes a switch to turn off the built-in LED lights. With the lights off, the MiScope Megapixel 2EF can be used on a light table, or with external lights for advanced lighting techniques.
The MiScope Megapixel 2EF includes our Video ToolBox PRO PC software, which adds enhanced measurement tools, a live on-screen reticle (or grid), and picture-in-picture freeze frame. It still allows you to capture still or moving images. You can also add labels, markers, time stamps, or draw on and make measurements directly on the live image.
An optional stand lets you position the MiScope-MP2 at the best location for large field-of-view imaging.
MiScope-MP2-EF image at 5X magnification |
MiScope-MP2-EF image of laser printed text at 120X magnification |
|
| Part Number | Price | |
| MISC-MP2EF-o2 | $745 | |
MISC-MP2EF-WUVIR $950
MiScope Megapixel 2 EF-WUVIR handheld digital microscope with 5 - 124X magnification lens, 2 megapixel camera and built-in LED lighting including white, UV and IR LEDs. Powered directly from the USB 2.0 port of any desktop or laptop computer. Includes Video ToolBox Pro PC software. One year warranty. When using MiScope MP2EF-WUVIR on a stand, do not use the UV or IR LEDs. Warning: Infrared light is harmful. Do not expose eyes or skin to rays. Warning: Ultraviolet light is harmful. Do not expose eyes or skin to rays. These units are not recommended for unsupervised use by children. |
||
- View live and capture images on the computer screen (or use a computer projector for large groups)
- 5— 124x magnification
- Completely portable with a laptop computer
- Save still images, movies and time lapse
- Labels, markers, time stamps, measurement, picture-in-picture
- Draw directly on the live image
- Video ToolBox PRO PC Software with enhanced measurement tools (Video ToolBox Premier Optional)
- Includes stacking shims for magnification adjustment
- Image Sensor: 1/3” CMOS
- Pixels: 1600 x 1200
- Frame Rate: 7.5 frames/second (up to 30 frames/second at reduced resolution)
- Power: USB 2.0 port
- Light Source: super-bright white LEDs (and optional UV & IR LEDs)
- Field of View:
- @5x: 60.5 x 81 mm
- @12X: 21 x 26 mm
@40X: 8 x 10 mm
@124X: 2 x 2.75 mm - Resolution: 2 microns
- Pentium IV 1.8 GHz or greater
(or Core Duo 1.6+ GHz) - Windows XP/7/8/10
- Mac OS X 10.6 or better (Mac Software Optional)
- Video card with 32MB+ memory
- DirectX 8.1 or greater
- Internet Explorer 5.0 or greater
- USB 2.0 port
- MP2EF Stand
- MP-PRE Kit
- MiScope-MP stand
- MiScope-MP filters
- Filter Wheel
